Multimeter Clamp Meter DT95 EX

Industrial intrinsically Safe Clamp Type Multimeter Clamp Meter DT95 EX

Display：50000 bit count backlight LCD

DC current range：1000ADC

DC voltage range：1000VDC

Temperature range：-100℃ ~ 1000℃/-148℉ ~ 1832℉

Product Introduction
Technical Parameters

Beling Dorland System Control Technology Co., Ltd. has recently launched the intrinsically safe industrial explosion-proof clamp type multimeter clamp Meter DT95 EX, which can measure up to 1000A DC current and up to 3000A AC current with true effective value clamp. Other functions include AC and DC voltage, resistance, continuity, capacitance, frequency, duty cycle, temperature, and diode testing. The built-in fiashlight and non-contact AC voltage detector provide more convenience, Bluetooth communication allows reading to be displayed and stored on mobile devices.

In addition, it is also suitable for outdoor construction, pipeline inspection, etc, and can be used in conjunction with various applications such as OA office systems, inspection positioning systems, data collection systems, etc. Especially suitable for harsh environments with hazardous explosions, such as petroleum, chemical, pharmaceutical, oil depots, tank areas, and other hazardous areas with flammable and explosive gases, facilitating timely communication between users and production and scheduling.

Clamp size：

≈48mm
Display：

50000 bit count backlight LCD
Low battery indicator:

Display "Occupy"
Over range indication:

Display "OL"
Measurement rate:

2 readings per second, nominal value
Working temperature:

5°C~40°C
Storage temperature:

-20°C~60°C
Working humidity:

Up to 80% to 31 ° C, linearly decreasing to 50% at 40 ° C
Battery:

A 9V battery
Automatic shutdown:

About 30 minutes later
Size and weight:

230 x 76 x 40mm;315g
DC current range and accuracy:

1000ADC，±(2.5%+5)
AC current range and accuracy:

3000AAC (flexible coil), ± (2.5%+5)
AC current range and accuracy:

1000AAC，±(2.5%+5)
DC voltage range and accuracy:

500.0mVDC/5.000VDC/50.00VDC/500.0VDC，±(0.1%+4)
DC voltage range and accuracy:

1000VDC，±(0.2%+5)
AC voltage range and accuracy:

400.0mVAC，4.000VAC，40.00VAC，750.0VAC，400.0VAC±(1.0%+9)
Resistance range and accuracy:

400.0Ω，±(1.0%+9)
Resistance range and accuracy:

4.000KΩ/40.00KΩ/400.0KΩ。±(1.0%+4)
Capacitance range and accuracy:

500.0nF，±(3.5%+40)
Capacitance range and accuracy:

5.000μF/50.00μF/500.0μF，±(3.5%+9)
Capacitance range and accuracy:

5.000mF，±(5.0%+9)
Frequency range and accuracy:

50.00Hz/500.0Hz/5.000KHz/50.00KHz/500.0KHz/5.000MHz/50.00MHz，±(0.3%+2)
Temperature range and accuracy:

100℃ ~ 1000℃ ±(1.0%+2℃)/-148℉ ~ 1832℉ ±(1.0%+3.6℉)
